Tri-Onic TR100R Class RK5 Time-Delay Fuse

Tri-Onic TR100R Class RK5 Time-Delay Fuse 100 Amp

Tri-onic
SKU:
S508
$30.00
$93.00
(You save $63.00 )
(No reviews yet)
Weight:
0.30 LBS
Width:
6.00 (in)
Height:
1.13 (in)
Depth:
1.13 (in)
Condition:
New
Current Stock:
1
Adding to cart… The item has been added
Description

Tri-Onic TR100R is a time-delay, current-limiting fuse in the TR-R series with a blade mounting form factor. It is rated 100 A and 250 VAC/250 VDC, and is identified as Class RK5. The fuse uses a fiberglass body and tin-plated copper blade terminals.

Overview

Tri-onic TR100R Dual Element Time Delay Fuse. Time-delay fuse. Current-limiting.

Verified Features

  • Time-delay fuse
  • Current-limiting
  • Class RK5
  • TR-R series
  • Blade mounting form factor
  • Fiberglass body
  • Tin-plated copper blade terminals
  • RoHS compliant

Technical Specifications

SeriesTR-R
Fuse ClassClass RK5
Fuse TypeTime Delay
FunctionCurrent-limiting overcurrent protection fuse
Ampere Rating100 A
Voltage Rating Ac250 VAC
Voltage Rating Dc250 VDC
Ac DcAC/DC
Frequency50/60 Hz
Interrupt Rating Ac200 kA
Interrupt Rating Dc20 kA
Mounting TypeBlade
Terminal TypeBlade
Connection Terminal MaterialTin-plated copper
Body TypeFiberglass
Body MaterialPolyTube
Overall Length5-7/8 in
Blade Height.7500 in
Blade Or Ferrule Length1.0000 in
Blade Width.1250 in
Rohs CompliantTrue
Ean Upc782001748012
Pack UnitEA
Diameter1.0625 in
Weight0.303 lb

Applications and Compatibility

  • Overcurrent protection of motors
  • Overcurrent protection of transformers
  • Overcurrent protection of service entrance equipment
  • Overcurrent protection of feeders
  • Overcurrent protection of branch circuits
Warranty
New Old Stock - Sold As-Is
