Danfoss 1872x8 Air Brake Adapter Tee 1/2 in Push-On x 3/8 in MIP Brass

Danfoss 1872x8 Air Brake Adapter Tee 1/2 in Push-On x 3/8 in MIP Brass

Danfoss
SKU:
S677
$25.00
$31.50
(You save $6.50 )
(No reviews yet)
Weight:
0.20 LBS
Width:
2.50 (in)
Height:
1.50 (in)
Depth:
1.00 (in)
Condition:
New
Current Stock:
8
Adding to cart… The item has been added
Description

Overview

Danfoss Weatherhead 1872X8 is a brass air brake adapter branch tee with two 1/2 in tube OD push-to-connect ends and one 3/8 in male pipe branch. It is configured as a three-port tee for air brake systems.

Verified Features

  • Three-port tee configuration
  • Push-to-connect tube ends
  • Male pipe threaded branch
  • Brass construction
  • Designed for air brake systems
  • Reusable
  • Field serviceable
  • Branch tee configuration
  • Quick-connect style
  • Three-port adapter

Technical Specifications

Series / FamilyWeatherhead
Connection Type RawPush-to-connect / male pipe / tee adapter
Branch Tee ConfigurationTee
Tube Size1/2 in
Thread Size3/8 in male pipe
End Configuration2 x 1/2 in tube OD push-to-connect, 1 x 3/8 in male pipe
Body MaterialBrass
Pressure RatingVacuum to 150 PSI
Temperature Rating-40 F to +200 F
ConformanceRef. SAE No. AA0425; meets D.O.T. FMVSS 571.106 and SAE J1131 air brake system performance requirements
Sealing MethodO-ring seal with pipe thread sealant on male threads
Quantity1
UomEA
Inlet Size1/2 in tube OD
Outlet Size1/2 in tube OD
Model Code Decode{'status': 'partially_resolved', 'family': '1872X series', 'variant': '8', 'note': 'Exact size/configuration resolved from exact-item evidence.'}

Applications and Compatibility

  • Air brake systems

Cross References

  • C1HY90 (Equivalent)
  • MINO-00015X03659 (Equivalent)
Warranty
New Old Stock - Sold As-Is
