C&C BF-030-LN-S-D-2-V-L LN200 Wafer Butterfly Valve, 3in, CF8M Stainless Disc, FKM Seat

C&C BF-030-LN-S-D-2-V-L LN200 Wafer Butterfly Valve, 3in, CF8M Stainless Disc, FKM Seat

C&C
SKU:
S663
$190.00
$300.00
(You save $110.00 )
(No reviews yet)
Weight:
6.50 LBS
Width:
9.50 (in)
Height:
6.00 (in)
Depth:
4.75 (in)
Condition:
New
Current Stock:
4
Adding to cart… The item has been added
Description

Overview

C&C LN200 Series wafer butterfly valve with short-neck design and 3 in. nominal size. Features ANSI 125/150 flange compatibility and 200 PSI NSCWP rating. No Handle included.

Verified Features

  • Wafer-style butterfly valve
  • LN200 series
  • Short-neck design
  • Notched body
  • Pinless disc
  • Lever or gear operated
  • ANSI 125/150 flange capable
  • Pressure rated to 200 PSI NSCWP

Technical Specifications

Series / FamilyLN200 Series
Valve TypeButterfly valve
Connection StyleWafer
SubstyleShort neck
Pressure Rating200 PSI NSCWP
Flange CompatibilityANSI 125/150
Body MaterialDuctile iron A536
Disc Material OptionsCF8M (316 SS)
Stem Material Options316 Stainless Steel
Seat Material OptionsFKM (Viton)
Retainer Pin MaterialASTM Gr. 1065 Steel
O Ring MaterialViton
Operating OptionsLever operated
Warranty
No Warranty
